    一分三快新品丨扁平线大电流一体成型电感
    发布时间：2023.08.29
    来源：一分三快科技集团

    • 1. 采用低损耗高密度金属粉材料

    • 2. 采用热喷涂技术,电感表面致密性好

    • 3. 闭合磁路设计,更好的抗电磁干扰

    • 4. 高密度压制成型，超高工作电流

    • 5. T core 扁平线工艺，超低直流电阻


    1. Utilization of low-loss high-density metal powder materials.

    2. Utilization of thermal spraying technology, ensuring excellent surface compactness of the inductor.

    3. Closed magnetic circuit design, providing enhanced electromagnetic interference resistance.

    4. High-density compression molding, capable of handling extremely high operating currents.

    5. T-core flat wire technique, achieving ultra-low direct current resistance.




    平板电脑，显示器，服务器，主板，大功率DC/DC模组


    Applied in tablets, monitors, servers, motherboards,high-power DC/DC modules









    Remark:
    1. All test data is reference to 25℃ ambient.
    2. Test Condition：1MHz，1Vrms
    3. Isat: Max.Value, DC current at which the inductance drops less than 30% from its value without current; Typ. Value, DC current at which the inductance drops 30% from its value without current.
    4. Irms: For Max. Value, ΔT＜40℃；for Typ. Value, ΔT is approximate 40℃.
    5. Operat between temperature range -40℃ to +125℃(Including self - temperature rise)
    6. Absolute maximum voltage: DC 60V




    产品损耗测试：
